Description
FuseBox F2006MX 6 Way RCBO Consumer Unit + Surge Protection
The FuseBox F2006MX consumer unit features 6 usable ways and comes with 100A Main Switch Incomer, Type 2 Surge Protection with 32A MCB, and a 32mm tails clamp.
As with all of the FuseBox T2 Surge Protected consumer units, the F2006MX has ample space internally for installing both the mini and standard height RCBOs.
Additional features include captive screws on the front cover, round knockouts on all four sides along with 2 large rectangular knockouts on the rear.
This consumer unit is supplied with an installation pack which includes a busbar, an icon label pack, and a grommet strip.
Key Features
- 6 usable ways
- 100A main switch incomer
- T2 surge protection & 32A MCB
- 32mm tails clamp included
- Earth and neutral terminal bars at the top
- Removable and raised DIN rail
- Round knock-outs on all faces
- Identification label pack
- Captive front cover screws
Additional Information
- Width 234mm x Height 259mm x Depth 113mm
- IP20XC
- BS EN61439-3
- RAL 9001 powder-coated finish
